Operating Limits:
-Max. liquid temperature: 35°C
-Min. diameter of well: 144mm
-Max. sand content: 0.25%
-Continuous duty

Motor:
-Rewindable enclosed induction motor or full obturated screen motor(n=2850r.p.m.)
-Built-in thermal overload protector with automatic reset
-Insulation Class B
-Protection IP58
-International Standard: IEC60335-1, IEC60335-2-41

Material:
-External pump body: S.S AISI304
-Suction strainer: S.S AISI304
-Impeller: thermoplastic resin PPO
-Diffuser: thermoplastic resin PPO
-Shaft: S.S AISI304-C1045
-Motor housing: S.S AISI304
-Mechanical seal: Graphite-Sic/hard alloy
-Discharge body: Cast brass ASTM250 or Cast iron G20 UNI5007 or S.S

Application:
-Multistage submersible water pumps for 3.5" deep wells.
-Water feeding plants for domestic and industrial applications; Fire fighting system for small and medium plants; Building pressurization plants.
-Water supply from wells or reservoirs, for garden use and irrigation.
